Servo iav twj tso kua mis

Servo Iav twj tso kua mis rau yas molding txhaj tshuab PGH Series Hydraulic iav twj tso kua mis Pgh4-3X/040re11vu2 Pgh4-30/040re11vu2





1.Siv axial thiab radial siab them nqi tsim, txawm nyob rau hauv qis ceev thiab tsawg viscosity tseem tuav lub siab volumetric efficiency.
2. Ultra-tsawg suab nrov, siv lub zog cam khwb cia hlau thiab sab hauv tsim tshwj xeeb ntsiag to, kom txo qis suab nrov.
3. Tsis tshua muaj dej ntws thiab siab pulsation, ntawm qhov ceev tsis tshua muaj peev xwm tswj tau ruaj khov txaus thiab siab tso zis.
4. Kev tsim qauv siab, qhov siab tshaj plaws mus txog 35Mpa.
5. Muaj ntau yam ceev, qhov siab tshaj plaws ceev mus txog 3000r / min, qis ceev 50 r / min.
6. tuaj yeem ua ke ua ke los ua ob lub twj tso kua mis.
7. Tsis rhiab rau cov roj paug, lub neej ua haujlwm ntev.
8. tuaj yeem siv dav hauv kev lag luam, xws li tshuab yas, khau tshuab, tshuab tuag-casting thiab forklift thiab lwm yam kev lag luam ntawm hydraulic system, tso cai rau nws siv nyob rau hauv servo zaus conversion tsav lub zog txuag system.



Qauv muaj
HG0 sib npaug PGH3, HG1 sib npaug PGH1, HG2 sib npaug PGH3
Ib leeg twj: HG0-8,10,13,16,20; HG1- 25, 32, 40, 50, 63; HG2-80,100,125,145,160
Ob chav twj: HG21,32, 31-(25,32,40,50,63,80,100,125,145,160), (25,32,40,50,63,80,100,125,145,160)








SIZE	DISP. cc/rov	HLOOV bar		ROTATING ceev r/min
		Rated	Max	Max	Min
HG0-10-01R-VPC	10	10	315	350	3000	600
HG0-13-01R-VPC	13	13.3	315	350	3000	600
HG0-16-01R-VPC	16	16	315	350	3000	600
HG0-20-01R-VPC	20	20	315	350	3000	600
HG1-25-01R-VPC	25	25.3	315	350	3000	200
HG1-32-01R-VPC	32	32.7	315	350	3000	200
HG1-40-01R-VPC	40	40.1	315	350	3000	200
HG1-50-01R-VPC	50	50.7	315	350	3000	200
HG1-63-01R-VPC	63	53.7	315	350	3000	200
HG2-80-01R-VPC	80	81.4	315	350	3000	200
HG2-100-01R-VPC	100	100.2	315	350	3000	200
HG2-125-01-VPC	125	125.3	315	350	3000	200
HG2-160-01-VPC	160	162.8	210	260	3000	200



Ntau tus qauv:

HG0-8-01R-VPC	HG0-10-01R-VPC	HG0-13-01R-VPC	HG0-16-01R-VPC
HG1-25-01R-VPC	HG1-32-01R-VPC	HG1-40-01R-VPC	HG1-50-01R-VPC
HG1-63-01R-VPC	HG0-20-01R-VPC	HG2-80-01R-VPC	HG2-100-01R-VPC
HG2-125-01R-VPC	HG2-160-01R-VPC	HG21-80-25-01R-VPC	HG22-160-80-01R-VPC
HG10-63-20-01R-VPC	HG10-63-16-01R-VPC	HG10-63-13-01R-VPC	HG10-63-10-01R-VPC
HG10-63-8-01R-VPC	HG10-50-8-01R-VPC	HG10-40-8-01R-VPC	HG10-32-8-01R-VPC
HG10-50-20-01R-VPC	HG10-50-16-01R-VPC	HG10-50-13-01R-VPC	HG10-50-10-01R-VPC
HG10-40-20-01R-VPC	HG10-40-16-01R-VPC	HG10-40-13-01R-VPC	HG10-40-10-01R-VPC
HG10-32-20-01R-VPC	HG10-32-16-01R-VPC	HG10-32-13-01R-VPC	HG10-32-10-01R-VPC
HG10-25-20-01R-VPC	HG10-25-16-01R-VPC	HG10-25-13-01R-VPC	HG10-25-10-01R-VPC
HG10-25-8-01R-VPC	HG11-63-25-01R-VPC	HG11-63-63-01R-VPC	HG11-63-50-01R-VPC
HG11-50-50-01R-VPC	HG11-50-40-01R-VPC	HG11-63-40-01R-VPC	HG11-63-32-01R-VPC
HG11-50-32-01R-VPC	HG11-50-25-01R-VPC	HG21-160-25-01R-VPC	HG21-125-25-01R-VPC
HG21-160-63-01R-VPC	HG21-160-50-01R-VPC	HG21-160-40-01R-VPC	HG21-160-32-01R-VPC
HG21-125-63-01R-VPC	HG21-125-50-01R-VPC	HG21-125-40-01R-VPC	HG21-125-32-01R-VPC
HG21-80-63-01R-VPC	HG21-80-50-01R-VPC	HG21-80-40-01R-VPC	HG21-80-32-01R-VPC
HG22-160-160-01R-VPC	HG22-160-125-01R-VPC	HG22-160-100-01R-VPC

















1. Pab neeg muaj zog technical
15 tus neeg tshawb fawb pab pawg, lub luag haujlwm rau kev txhim kho kev tshawb fawb thiab kev tsim khoom tshiab. Peb pawg kws tshaj lij txhua tus muaj ntau tshaj 20 xyoo kev paub ntawm cov twj tsim thiab engineering, peb tus kws tshaj lij muaj ntau tshaj 40 xyoo dhau los ntawm cov twj tsim.



2. Tus nqi sib tw
Vim muaj kev tswj xyuas zoo, peb cov nqi sib tw ntau dua li cov khoom qub, tsim nyog ntau dua li cov khoom siv hauv tsev.



3. Lub sijhawm xa khoom sai
Peb tuaj yeem xa cov xaj me me hauv ib lub lis piam, rau kev txiav txim loj xws li hauv 500 PCS twj los yog cov khoom siv cartridge feem ntau peb tuaj yeem ua cov khoom xa tuaj hauv ib hlis.


Cim npe nrov: servo iav twj tso kua mis, Tuam Tshoj servo iav twj tso kua mis manufacturers, lwm tus neeg, Hoobkas
